Normally the value shall be between 32 and 112 (standard range). Values
below 32 indicate detector fault. Values between 112/128 indicate
prewarning, and values above 128 indicate fire alarm.
The sequence is terminated by pressing the ↵
↵↵
↵ key. Another address may
now be selected.
If the sensitivity (analogue signal) from all detectors in a loop is to be
checked, the loop number has to be selected from this text in the display:
ADDRESS SENSITIVITY
LOOP 00 RET MM
When the loop number in question is selected with the arrow keys and the
↵
↵↵
↵ key, the following text will appear in the display:
(when selecting loop 01).
ADDRESS LOOP 01
PRINTER DISPLAY RET MM
In this sequence it is possible to select between a print-out from the optional
printer, or an indication in the display. The selection is carried out by
moving the cursor to "PRINTER" or "DISPLAY" with the arrow keys and
then press the ↵
↵↵
↵ key. The sensitivity value for one detector will remain in
the display for about 1 second before changing to the next detector.
This sensitivity sequence can be terminated by pressing the ↵
↵↵
↵ key. The
sequence is automatically terminated when the sensitivity of all detectors
has been indicated in the display:
If a total sensitivity check is to be carried out, select the "TOTAL" menu
option under the "ADDRESS" sequence by moving the cursor to "TOTAL"
with the arrow keys and press the ↵
↵↵
↵ key. The sequence is carried out the
same way as described above and a selection between printer or display can
be made.
