66 Model E1070 Indicator User Instructions
Communications
The E1070 provides an RS-232 output for data transmission to a peripheral
device. Contact your local Avery Weigh-Tronix supplier or distributor for
assistance on RS-232 interface connections.
The default serial port parameters
are 9600 baud, 8 databits, no parity
and 1 stop bit.
Stop bits for the serial
communication are preset to 1
stop bit. This is not configurable.
If your indicator has a peripheral device connected, from the gross/net
weighing mode press the PRINT key to transmit the selected output(s).
The PRINT annunciator will illuminate while data is transmitted and the data
configured to be printed will be output to the printer.
Following are the default print formats
Print Formats 1-8 are for the Zebra Thermal printer. See examples in Figure
on the following pages.
Print Formats 9-15 are for a standard ASCII characters for use with dot
matrix printer.
Print Formats 9 & 10
G 123456 lb
{ACT}{DSP}{UN}<CR><LF>{EOS}
Accumulator (Print Format 11), Batching (12) and Checkweigher (13)
all use the following:
G 123456 lb
{ACT}{DSP}{UN}<CR><LF>{EOS}
Counting, Print Format 14
Piece Count: 48
Piece Count: {CNT}<CR><LF>{EOS}
Peak Print Format 15
123456 lb
{PWT} {UN}<CR><LF>{EOS}
Remote Display Print Format 16
G 123456 lb
{ACT} {DSP} {UN}<CR><LF>{EOS}
Communications
6
