EN3EN 2
CONTENTS
A - SAFETY
INSTRUCTIONS
1 - OPERATING PRECAUTIONS 04
2 - INSTALLATION PRECAUTIONS 04
3 - MAINTENANCE AND CLEANING 05
4 - RECYCLING 05
B - PRODUCT
DESCRIPTION
1 - KIT CONTENTS 06
2 - EQUIPMENT REQUIRED (NOT
INCLUDED) 06
C - INSTALLATION
HAZARD ANALYSIS 07
1 - ELIMINATING RISKS 08
2 - INSTALLING ACTUATORS 09
2.1 - maximum opening angle 10
3 - INSTALLING THE SWITCHGEAR 14
4 - INSTALLING THE FLASHING LIGHT 15
5 - INSTALLING THE SET OF PHOTOCELLS
(optional) 16
6 - CONNECTIONS 18
6.1 - The mains electricity 19
6.2 - Actuators 20
6.3 - Flashing light 20
6.4 - Photocells (optional) 20
6.5 - Control parts (optional) 21
6.6 - Backup battery (optional ref 580293) 21
6.7 - Solar power kit (optional ref. 114373) 21
D - BEGINNING
OPERATION
1 - SETTINGS INTERFACE 22
2 - QUICK SETTINGS 22
2.1 - Self-learning 22
2.2 - Adding remote controls 23
2.2.1 - Programming with the card 24
2.2.2 - Copy programming 24
2.3 - DELETING ALL REMOTE CONTROLS 24
3 - ADVANCED SETTINGS 24
3.1 - Menu 1 26
3.1.1 - Operating mode (automatic or
semi-automatic closing) 27
3.1.2 - Time delay (for automatic mode) 27
3.1.3 - Motor force 28
3.1.4 - Motor speed 28
3.2 - Menu 2 28
3.2.1 - Acceleration/deceleration at end of
travel 29
3.2.2 - Photocell mode 29
3.2.3 - Type of gate 30
3.2.4 - Stop tolerance 30
3.3 - Menu 3 31
3.3.1 - Closing time interval 31
3.3.2-Flashinglightpre-ashingtime 31
