Avidsen V250 - Installing the Flashing Light

EN15
C - INSTALLATION
4 - INSTALLING THE FLASHING LIGHT
Theashinglightmustbeattachedtothetopofthepostonwhichtheswitchgearismounted,anditmust
be visible from both the inside and the outside.
• Unscrewtheupperpartoftheashinglight
• Drill two holes in the bottom of the case to pass the two screws that will secure it to the post.
•Attachtheashinglightontothepost.
•Closethelightbyscrewingtheupperpartoftheashinglightbackon.
Connecttheashinglightbylocatingthecolourofthewiresinordertotransferthemtotheelectroniccard.
