EN11
C - INSTALLATION
Overview
actuators
photocells
Mandatory central stop
(not included)
Mandatory side stops
(not included)
Inner side of the property
Flashing light
Switchgear
Attaching the post mounting bracket
Mount the actuators to a rigid and reinforced part of the gate (e.g. the frame or the crossbar). Mount them
as low as possible for aesthetic and technical reasons.
CORRECT IDEAL
The instructions below describe installation of the left actuator; to install the right actuator, repeat the
process while respecting the symmetry.
