5-54
Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION
Input bit function
Four kinds of input bit functions are provided. The required functions can be
configured by the user.
Item (Bank) Display Contents Initial value User level
Internal Contact 1 Input bit
operation
(DI Assignment bank)
0: Not used (Default input)
1: Function 1 ((A and B) or (C and D))
2: Function 2 ((A or B) and (C or D))
3: Function 3 (A or B or C or D)
4: Function 4 (A and B and C and D)
0 High function
Internal Contact 2 Input bit
operation
(DI Assignment bank)
0
Internal Contact 3 Input bit
operation
(DI Assignment bank)
0
Internal Contact 4 Input bit
operation
(DI Assignment bank)
0
Internal Contact 5 Input bit
operation
(DI Assignment bank)
0
• When the set value is “0”, the input bit function is not used and the default input
is used. The following shows the default input of each internal contact:
Internal Contact 1: digital input (DI) 1
Internal Contact 2: digital input (DI) 2
Internal Contact 3: digital input (DI) 3
Internal Contact 4: digital input (DI) 4
Internal Contact 5: OFF status
• In the input bit function, the logical operations (AND, OR) of each of internal
contacts 1 to 5 are combined. In input bit functions 1 to 4, the combination of the
logical operations may vary. The following shows one logical operation:
Logical AND Logical OR
OFF and OFF = OFF OFF or OFF = OFF
ON and OFF = OFF ON or OFF = ON
ON and ON = ON ON or ON = ON
• “OFF” is “contact open (OPEN)” or “0” when expressed using the numerical
value.
• “ON” is “contact close (CLOSE)” or “1” when expressed using the numerical
value.
