Azbil C35 Series User Manual

5-115
Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION

Input with motor fully closed and input with motor fully open
Item (Bank) Display Contents Initial value User level
Input with motor fully
closed
(Setup bank)
0 to 9999 1000 Basic,
Standard,
High function
Input with motor fully
open
(Setup bank)
0 to 9999 3000
• When the control output type is R1 (motor drive relay output), the display and
setting can be performed. However, if [
C57
: Position proportional type] is set
at “2” (Estimated position control) or “3” (Estimated position control + Position
adjustment at power ON), the display and setting cannot be performed.
• If you use the motor auto adjust function of the position proportional control,
these parameters can be set automatically. Additionally, they can also be set
manually in the same manner as described for normal set values.
• The difference in the settings for [
C6

1
: Input with motor fully closed] and [
C62
:
Input with motor fully open ] must be 260 or more, and
C6

1
(fully closed) must
be less than
C62
(fully open). Otherwise,
AL

10
will occur. Please set a value
from 144 to 5782 for [
C6

1
: Input with motor fully closed] and [
C62
: Input with
motor fully open]. A value outside this range will cause
AL07
.
• If
AL

10
is generated and automatic motor adjustment (
C60
) cannot be started,
set values that meet the above conditions. After
AL

10
disappears, start the
adjustment. (Sample settings:
C6

1
= 1000,
C62
= 3000,
C63
= 30.0s)
Note
For details about motor auto adjust,


Motor adjust (p.5-111).

Motor full close–full open time
Item (Bank) Display Contents Initial value User level
Motor full close–full open
time
(Setup bank)
5.0 to 240.0s 30.0s Basic,
Standard,
High function
• When the control output type is R1 (motor drive relay output), the display and
setting can be performed.
• When using the motor auto adjust function of the position proportional control
with [
C57
: Position proportional type] set at “0” (MFB control + Estimated
position control) or “1” (MFB control), the motor full close–full open time can
be set automatically. Additionally, this time can also be set manually in the same
manner as described for normal set values.
Note
For details about motor auto adjust,


Motor adjust (p.5-111).
• When [
C57
: Position proportional type] is set at “2” (Estimated position
control) or “3” (Estimated position control + Position adjustment at power ON),
the actually measured motor full open time is set.
