D-3
Analog inputControl actionsSP
SPContinuous outputsPosition proportional
CommunicationsKey operations and displays
Bank selection
Operation displays
Some items are not displayed depending on the availability of optional functions, model number,
display setup (
C73
to
C78
) and User level (
C79
).
Pressing [display] key while bank item or user function item is displayed has the effect of canceling
and returning to the operation display item.
[display] key
Heat manipulated
variable
MV value
PV value
AT progress
value
CT1
Current value
CT2
Current value
Internal event 2
sub-setting
Setting value
Internal event 2
main setting
Setting value
Timer remaining
time 1
Internal event 1
delay time
Internal event 1
sub-setting
Setting value
Internal event 1
main setting
Setting value
Cool manipulated
variable
MV value
MFB
MFB value
[Setup] [Lock]
[ ] key
[enter] key
[
Instrument information
]
2-second
press +
hold of
[para] key
[
Event configuration
] [
DI assignment
] [
DO assignment
] [User function]
[para] key
or
[
] key
*1 The parameters and numerical values registered as user functions
UF
are displayed.
*2 In the RSP mode,
RSP
and
PI
D.r
are displayed first.
*3 If no key is pressed for 3 minutes, the display automatically returns to 2, the basic display.
Explanation of arrows
[display] key :
[para] key, [ ] key, [para] key or [ ] key :
[enter] key :
Movement through each setup menu
• [
] key
• [para] key or [
] key
To Next Page
