Azbil C35 Series User Manual

9-2
Chapter 9. LIST OF COMMUNICATION DATA
Bank Item name
RAM address EEPROM address RAM EEPROM
Decimal
point
information
Notes
Decimal Hexadecimal Decimal Hexadecimal Read Write Read Write
Setup PV range low limit 5205 1455 21589 5455 * * P
PV range high limit 5206 1456 21590 5456 * * P
SP low limit 5207 1457 21591 5457 P
SP high limit 5208 1458 21592 5458 P
PV square root extraction dropout 5209 1459 21593 5459 * * 1
RSP input range type 5210 145A 21594 545A * * —
RSP range low limit 5211 145B 21595 545B * * P
RSP range high limit 5212 145C 21596 545C * * P
PID calculation adjustment function 5213 145D 21597 545D — (Note 1)
Control action (Direct/Reverse)
5214 145E 21598 545E —
Output operation at PV alarm 5215 145F 21599 545F —
Output at PV alarm 5216 1460 21600 5460 1
Output at READY (Heat) 5217 1461 21601 5461 1
Output at READY (Cool) 5218 1462 21602 5462 1
Output operation at changing
Auto/Manual
5219 1463 21603 5463 —
Preset MANUAL value 5220 1464 21604 5464 1
Initial output type (mode) of PID
control
5221 1465 21605 5465 —
Initial output of PID control 5222 1466 21606 5466 1
PID decimal point position 5223 1467 21607 5467 —
Zone PID operation 5224 1468 21608 5468 —
(Reserved for future extension.) 5225 1469 21609 5469
∆
X
∆
X —
Heat/Cool control 5226 146A 21610 546A —
Heat/Cool 5227 146B 21611 546B —
Heat/Cool control dead zone 5228 146C 21612 546C 1
Heat/Cool change point 5229 146D 21613 546D 1
LSP system group 5230 146E 21614 546E —
SP ramp type 5231 146F 21615 546F —
SP ramp unit 5232 1470 21616 5470 —
STEP time unit 5233 1471 21617 5471 —
STEP PV start 5234 1472 21618 5472 —
STEP loop 5235 1473 21619 5473 —
CT1 operation type 5236 1474 21620 5474 —
CT1 output 5237 1475 21621 5475 —
CT1 measurement wait time 5238 1476 21622 5476 —
CT2 operation type 5239 1477 21623 5477 —
CT2 output 5240 1478 21624 5478 —
CT2 measurement wait time 5241 1479 21625 5479 —
Control output 1 range 5242 147A 21626 547A —
Control output 1 type 5243 147B 21627 547B —
Control output 1 scaling low limit 5244 147C 21628 547C S
Control output 1 scaling high limit 5245 147D 21629 547D S
Control output 1 MV scalable
bandwidth
5246 147E 21630 547E P (Note 2)
Control output 2 range
5247 147F 21631 547F —
Control output 2 type 5248 1480 21632 5480 —
Control output 2 scaling low limit 5249 1481 21633 5481 S
Control output 2 scaling high limit 5250 1482 21634 5482 S
Control output 2 MV scalable
bandwidth
5251 1483 21635 5483 P (Note 2)
Auxiliary output range
5252 1484 21636 5484 —
Auxiliary output type 5253 1485 21637 5485 —
(Continue on next page.)
