Chapter 9. LIST OF COMMUNICATION DATA
Bank
Item name
RAM address EEPROM address RAM EEPROM
Decimal
point
information
Notes
Decimal
Hexadecimal
Decimal
Hexadecimal
Read Write Read Write
DI
Assignment
Internal Contact 5 Polarity A
5455 154F 21839 554F —
Internal Contact 5 Polarity B
5456 1550 21840 5550 —
Internal Contact 5 Polarity C
5457 1551 21841 5551 —
Internal Contact 5 Polarity D
5458 1552 21842 5552 —
Internal Contact 5 Polarity
5459 1553 21843 5553 —
Internal Contact 5 Internal event
No. assignment
5460 1554 21844 5554 —
DO
Assignment
Control output 1 Operation type
5601 15E1 21985 55E1 —
Control output 1 Output assignment A
5602 15E2 21986 55E2 —
Control output 1 Output assignment B
5603 15E3 21987 55E3 —
Control output 1 Output assignment C
5604 15E4 21988 55E4 —
Control output 1 Output assignment D
5605 15E5 21989 55E5 —
Control output 1 Polarity A
5606 15E6 21990 55E6 —
Control output 1 Polarity B
5607 15E7 21991 55E7 —
Control output 1 Polarity C
5608 15E8 21992 55E8 —
Control output 1 Polarity D
5609 15E9 21993 55E9 —
Control output 1 Polarity
5610 15EA 21994 55EA —
Control output 1 Latch
5611 15EB 21995 55EB —
Control output 2 Operation type
5612 15EC 21996 55EC —
Control output 2 Output assignment A
5613 15ED 21997 55ED —
Control output 2 Output assignment B
5614 15EE 21998 55EE —
Control output 2 Output assignment C
5615 15EF 21999 55EF —
Control output 2 Output assignment D
5616 15F0 22000 55F0 —
Control output 2 Polarity A
5617 15F1 22001 55F1 —
Control output 2 Polarity B
5618 15F2 22002 55F2 —
Control output 2 Polarity C
5619 15F3 22003 55F3 —
Control output 2 Polarity D
5620 15F4 22004 55F4 —
Control output 2 Polarity
5621 15F5 22005 55F5 —
Control output 2 Latch
5622 15F6 22006 55F6 —
Event output 1 Operation type
5623 15F7 22007 55F7 —
Event output 1 Output assignment A
5624 15F8 22008 55F8 —
Event output 1 Output assignment B
5625 15F9 22009 55F9 —
Event output 1 Output assignment C
5626 15FA 22010 55FA —
Event output 1 Output assignment D
5627 15FB 22011 55FB —
Event output 1 Polarity A
5628 15FC 22012 55FC —
Event output 1 Polarity B
5629 15FD 22013 55FD —
Event output 1 Polarity C
5630 15FE 22014 55FE —
Event output 1 Polarity D
5631 15FF 22015 55FF —
Event output 1 Polarity
5632 1600 22016 5600 —
Event output 1 Latch
5633 1601 22017 5601 —
Event output 2 Operation type
5634 1602 22018 5602 —
Event output 2 Output assignment A
5635 1603 22019 5603 —
Event output 2 Output assignment B
5636 1604 22020 5604 —
Event output 2 Output assignment C
5637 1605 22021 5605 —
Event output
2
Output assignment D
5638 1606 22022 5606 —
Event output 2 Polarity A
5639 1607 22023 5607 —
Event output 2 Polarity B
5640 1608 22024 5608 —
Event output 2 Polarity C
5641 1609 22025 5609 —
Event output 2 Polarity D
5642 160A 22026 560A —
Event output 2 Polarity
5643 160B 22027 560B —
Event output 2 Latch
5644 160C 22028 560C —
