Azbil C35 Series User Manual

1-2
Chapter 1. OVERVIEW

Model selection table
The following shows the model selection table of this unit:
Basic
model No.
Mounting Control
output
PV
input
Power
supply
Option Additional treatment Specifications Notes
1 2 1 2
C35
SDC35 Mask size 48 mm
× 96 mm
C36
SDC36 Mask size 96 mm
× 96 mm
T Panel mounting type
Control output 1 Control output 2
R0 Relay output NO
None (relay output for
control output 1: NC)
(Note 1) R1 Motor drive relay output
OPEN side
Motor drive relay output
CLOSE side
With
MFB
V0 Voltage pulse output
(for SSR drive)
None (for SSR drive)
VC Voltage pulse output
(for SSR drive)
Current output
VD
Voltage pulse output
(for SSR drive)
Continuous voltage output
VV Voltage pulse output
(for SSR drive)
Voltage pulse output
(for SSR drive)
C0 Current output None
CC Current output Current output
CD Current output
Continuous voltage output
D0 Continuous voltage output None
DD
Continuous voltage output Continuous voltage output
U Universal
A AC Model (100 to 240 V AC)
D DC Model (24 V AC/24 V DC)
1 Event relay outputs 3 points
2 Event relay output: 3 points, auxiliary output (current output)
3 Event relay output: 3 points, auxiliary output (voltage output)
(Note 1)
4 Event relay output: 2 points (independent contact)
(Note 1) 5 Event relay output: 2 points (independent contact),
auxiliary output (current output)
(Note 1) 6 Event relay output: 2 points (independent contact),
auxiliary output (voltage output)
0 None
(Notes 2, 3) 1 Current transformer input: 2 points,
Digital input: 4 points
(Notes 2, 3) 2 Current transformer input: 2 points,
Digital input: 4 points, RS-485 communication
(Notes 2, 3) 3 Current transformer input: 2 points,
Digital input: 2 points, RSP input
(Notes 2, 3) 4
Current transformer input: 2 points, Digital input: 2
points, RSP input, RS-485 communication
(Note 4) 0 No additional treatment
D Inspection Certificate provided
Y Complying with the traceability certification
Note 1. Can not be selected for the DC Model. 0 None
Note 2. Current transformer sold separately. A UL-marked product
Note 3. When the control output is R1, the current transformer input is not applied. MFB input is applied instead.
Note 4. Additionally, tropicalization and anti-sulfidation treatments can be ordered. However, there are some
specifications restrictions. For details, contact the azbil Group.
