2-4
Chapter 2. OUTLINE OF FUNCTIONS
Data setting procedures
Two types of data setting procedures are provided, standard type and special type.
A desired type can be selected using the setup bank [
C7
1
: Key operation mode/
type].
Standard type: The [enter] key is used to start changing the setup value and
to set the value currently being changed.
Special type: The [<], [
], or [
] key is used to start changing the setup
value. To set the value currently being changed, wait for 2 s
without pressing of any key. (However, only the standard type
operation can be performed in the bank setup display mode.)
Type setup
Display mode
Setup bank
C7
1
= 0
Setup bank
C7
1
= 1
Operation display Standard type Special type
Bank setup display Standard type Standard type
User function setup display Standard type Special type
Standard type
(1) Operate the [display], [para], [<], [
], or [
] key to display desired data to be
set.
(How to display the data is explained in "General flow of key operation"
described previously.)
pv
sp
pv
sp
(This Figure shows the display when
setting the PV range type of the setup
setting [
C01
].)
(This Figure shows the display when
setting the RUN/Ready selection in
the parameter setting [r--r].)
(2) Press the [enter] key.
>> When the lower display shows a numeric value, the 1st digit starts flashing.
Additionally, when the lower display shows a character string, the entire
character string starts flashing.
When a numeric value is displayed, the value can be increased or decreased
or the flashing digit can be moved using the [<], [
], or [
] key.
When a character string is displayed, the entire flashing character string
can be changed using the [
], or [
] key.
pv
sp
pv
sp
(This Figure shows the display when
the 1st digit of "
0001
" is ashing.)
(This Figure shows the display when
the entire character string "
rUn
" is
ashing.)
To Next Page
