Azbil JTD910S User Manual

4-13
Chapter 4 Maintenance and Troubleshooting of this Device
Table 4-3.
HART5
Diagnostics Display Message Description
Critical Status
Analog/Digital Conversion Fault
An error occurred during analog-to-digital
conversion.
Sensor Characteristic Data Fault
An error was detected in the sensor characteristic
data.
Suspect Input Input data error
CPU Fault CPU operation failure
NVM Fault Nonvolatile memory error
RAM Fault RAM failure
ROM Fault ROM failure
Output Circuit Fault Output circuit failure
Internal Data
Inconsistency
Invalid Database Configuration data and/or calibration data is invalid.
Non-Critical
Status
Meter Body Over Temperature Meter body is too hot.
Excess Zero Correct
The zero Calibration Value exceeds the limit for
accurate measurement.
Excess Span Correct
The span Calibration Value exceeds the limit for
accurate measurement.
Meter Body Overload or Fault
Indicates whether the present output level is higher
than the Output Alarm High Limit setting.
Correct Reset Clears the calibration data.
External Zero/Span Adjustment Fault
The zero Calibration Value exceeds the limit for
accurate measurement.
Output Alarm Deected
The output is going over upper/lower limit of output
alarm.
Sensor Temp. Alarm Detected
The sensor temperature is going over upper/lower
limit of sensor temp. alarm.
