Azbil JTD910S User Manual

4-14
Chapter 4 Maintenance and Troubleshooting of this Device
Table 4-3.
HART7
Diagnostics Display Message Description
Failure
Analog/Digital Conversion Failure
An error occurred during analog-to-digital
conversion.
Sensor Characteristic Data Failure
An error was detected in the sensor characteristic
data.
Suspect Input Input data error
CPU Failure CPU operation failure
NVM Failure Nonvolatile memory error
RAM Failure RAM failure
ROM Failure ROM failure
Output Circuit Failure Output circuit failure
Invalid Database Configuration data and/or calibration data is invalid.
Out of
Specification
Meter Body Over Temperature Meter body is too hot.
Meter Body Overload or Failure
The input pressure is more than two times the upper
range limit for the device. Or,-Device error
High Output Alarm
Indicates whether the present output level is higher
than the Output Alarm High Limit setting.
Low Output Alarm
Indicates whether the present output level is lower
than the Output Alarm Low Limit setting.
High Sensor Temp. Alarm
Indicates whether the present sensor temperature
is higher than the Sensor Temp. Alarm High Limit
setting.
Low Sensor Temp. Alarm
Indicates whether the present sensor temperature is
lower than the Sensor Temp. Alarm Low Limit setting.
Maintenance
Required
External Zero/Span Adjustment Failure
An error occurred during external adjustment of the
zero point or span.
Excess Zero Calibration Value
The zero Calibration Value exceeds the limit for
accurate measurement.
Excess Span Calibration Value
The span Calibration Value exceeds the limit for
accurate measurement.
Not Calibrated Clears the calibration data.
Pressure Frequency Index Alarm Check Process and/or Impulse Line.
Standard Deviation Alarm Check Process Conditions.
Out-of-Range Count Alarm Check Operating Conditions.
4-3-3 Zero Calibration Internal Data
This concerns the zero point calibration data saved in the transmitter. The function saves zero
point calibration data, which can be read using a communicator. By viewing shifts in the zero
calibration value, the transmitter maintenance interval and replacement period can be estimated
Field Communication Software (Model CFS100) Instruction Manual
(HART5) Section 4-6 / (HART7) Section 3-6
HART Communicator Operation Manual
(HART5) No display capability on HART communicator / (HART7) Section 3-4-3
