Azbil JTD910S User Manual

Appendix B Range Damping Time Constant Settings at Time of Factory Shipping
B-1
Appendix B
The following are the range settings at the time of factory shipping during coarse adjustment.
If a range specification is received from the customer, the product ships with the specified range.
Type SI units LRV URV
JTD910 _ Pa 0 500
JTD920 _ kPa 0 50
JTD921 _ kPa 0 50
JTD930 _ kPa 0 350
JTD931 _ kPa 0 350
JTD960 _ MPa 0 7
JTD961 _ MPa 0 7
JTC929 _ kPa 0 50
JTC940 _ MPa 0 0.7
JTE929 _ kPa 0 50
JTE930 _ kPa 0 350
JTG940 _ MPa 0 2
JTG960 _ MPa 0 7
JTG980 _ MPa 0 20
JTH920 _ kPa 0 50
JTH940 _ kPa 0 700
JTH960 _ MPa 0 2
JTH980 _ MPa 0 20
JTA922 _ kPa abs 0 13
JTA940 _ MPa abs 0 2
JTS922 _ kPa abs 0 13
JTS940 _ MPa abs 0 0.7
Damping time constant at time of factory shipping*
Type
Adjustment span (X) according to damping time constant
4 s 2 s 1 s
JTD910 _ - 0.1 kPa ≤ X < 2 kPa -
JTD920 _ 5 kPa ≤ X < 2.5 kPa 2.5 kPa ≤ X < 5 kPa 5 kPa ≤ X
JTD921 _ 0.75 kPa ≤ X < 2.5 kPa 2.5 kPa ≤ X < 5 kPa 5 kPa ≤ X
JTD930 _
35 kPa ≤ X < 45 kPa 45 kPa ≤ X < 90 kPa 90 kPa ≤ X
JTD931 _ 35 kPa ≤ X < 45 kPa 45 kPa ≤ X < 90 kPa 90 kPa ≤ X
JTD960 _ 0.25 MPa ≤ X < 0.7 MPa 0.7 MPa ≤ X < 1.4 MPa 1.4 MPa ≤ X
JTD961 _ 0.25 MPa ≤ X < 0.7 MPa 0.7 MPa ≤ X < 1.4 MPa 1.4 MPa ≤ X
JTC929 _ - 2.5 kPa ≤ X < 5 kPa 5 kPa ≤ X
JTC940 _ 70 kPa ≤ X < 80 kPa 80 kPa ≤ X < 210 kPa 210 kPa ≤ X
JTE929 _ - 2.5 kPa ≤ X < 5 kPa 5 kPa ≤ X
JTE930 _ 35 kPa ≤ X < 45 kPa 45 kPa ≤ X < 90 kPa 90 kPa ≤ X
JTG940 _ 17.5 kPa ≤ X < 80 kPa 80 kPa ≤ X < 210 kPa 210 kPa ≤ X
JTG960 _ - 0.7 MPa ≤ X < 1.4 MPa 1.4 MPa ≤ X
JTG980 _ - 0.7 MPa ≤ X < 1 MPa 1 MPa ≤ X
JTH920 _ - 2.5 kPa ≤ X < 5 kPa 5 kPa ≤ X
JTH940 _ 35 kPa ≤ X < 80 kPa 80 kPa ≤ X < 210 kPa 210 kPa ≤ X
JTH960 _ - 0.7 MPa ≤ X < 1.4 MPa 1.4 MPa ≤ X
JTH980 _ - 0.7 MPa ≤ X < 1 MPa 1 MPa ≤ X
JTA922 _ - 4 kPa abs ≤ X < 5 kPa abs 5 kPa abs ≤ X
JTA940 _
35 kPa abs ≤ X < 80 kPa abs 80 kPa abs ≤ X < 210 kPa abs 210 kPa abs ≤ X
JTS922 _ - 4 kPa abs ≤ X < 5 kPa abs 5 kPa abs ≤ X
JTS940 _ 35 kPa abs ≤ X < 80 kPa abs 80 kPa abs ≤ X < 210 kPa abs 210 kPa abs ≤ X
*If a specification is received from the customer, the product ships with the separately specified value.
