5-5 : Configuration of OPERATOR'S MODE
Introduction
OPERATOR'S MODE provides the following setting and adjustment items.
For details on functions in the items, see “5-5-1 : Changing setting of damping time
constant” and later.
Item Contents Screen
DAMPING Sets a damping time
constant.
AUTO ZERO Auto zero adjustment
CNT-RESET VALUE Sets a built-in counter reset
value.
CNT-RESET READY Resets totalized value to a
built-in counter reset value.
SPIKE CUT Sets auto spike cut.
AVERAGING Sets a moving average
function.
ELECTRODE_ST
SENSITIVITY
Sets electrode status
diagnostic function.
Selects a sensitivity level of
electrode status diagnostic
function.
ELECTRODE_ST
OUTPUT MODE
Sets output mode when the
electrode status diagnostic
function detects the empty or
scale on electrode condition.
DISP SELECT Selects either % flow rate,
actual flow rate or totalized
value to be displayed in the
main display.
20.0 %
* DAMPING
005.0 s
20.0 %
* AUTO ZERO
READY
20.0 %
* CNT-RESET VALUE
0004444
20.0 %
* CNT-RESET READY
00000000
20.0 %
* SPIKE CUT
OFF
20.0 %
* AVERAGING
OFF
20.0 %
* ELECTRODE
_
ST
SENSITIVITY OFF
20.0 %
* ELECTRODE
_
ST
OUTPUT MODE OFF
20.0 %
* DISP SELECT
%
