Instrument installation Azbil Corporation
2-26 Model MTG11A/18A, MTG11B/18B, MTG14C
2-2-2 : Installation a flange type detector
Basic installation method
Installation example
Figure 2-20 shows the basic method for installing the device.
Fastening torque
Figure 2-24 Installation example
m CAUTION
Be careful in handling this unit. It is heavy, dropping it accidentally could cause
injury.
m WARNING
Table 2-5 shows the fastening torque for each pipe bore. Apply the prescribed
fastening torque to prevent leakage.
Nuts
Through-bolts
Pipe
Gasket
(Required when the grounding
ring is made of SUS material.
In other cases, the gasket is
supplied.)
CM2-MTG300-2001.book 26 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
