Operation using the data setting device Azbil Corporation

6-10 Model MTG11A/18A, MTG11B/18B, MTG14C

Charging SFC

Procedure

For the procedure for charging the SFC, see the SFC User's Manual (CM2-SFC100-

2001).

m CAUTION

When a “:” mark appears in the 8th column at the top of the SFC screen as shown

below, stop using the SFC immediately and charge the SFC. Continuing to use the

SFC will over discharge the battery of the SFC and make it impossible to charge it

further.

SFCM00006001D

CM2-MTG300-2001.book 10 ページ２０１５年９月２９日　火曜日　午前１０時１４分
