Azbil Corporation Operation using the data setting device

Model MTG11A/18A, MTG11B/18B, MTG14C 6-35

Displaying software version: SW VER key

Procedure

Use the following procedure to confirm the software version of the SFC and the

converter connected to the SFC used.

Step

Key Procedure SFC screen

1 Make sure that the SFC is set to

“READY”.

If it is not, press the key to set it

to “READY”.

Press the key.

Press the (SW VER) key.

Result:

- The software version is displayed.

4 After confirming the software version,

press the key to return to the

screen in step 1.

CLR

( No )

CLR

( No )

SFCM00006009D

SHIFT

SFCM00006002D

SW VER

SFCM00006066D

CLR

( No )

CLR

( No )
