Azbil Corporation Operation using the data setting device

Model MTG11A/18A, MTG11B/18B, MTG14C 5-35

6 Press the  key to move the cursor to the position

under *.

Pressing the MODE key reboots the converter,

returns to MEASURING MODE, and the

communication system changes and saved.

m CAUTION

You have only ten minutes to return to MEASURING MODE to save the new value before

the system resets it to the previously saved value.

Step Procedure Screen

20.0 %

COM SELECT

HART

8.8.8.8.8.8.8.8

RATE

TOTAL

SELF CHECK

MODE

20.0 %

01.94 m

WP0 00069401
