Operation using the data setting device Azbil Corporation
6-38 Model MTG11A/18A, MTG11B/18B, MTG14C
Printing example
The following shows an example of an actual configuration printout accompanied by
line-by-line descriptions.
Printing example Meaning
‘02-01-01 00:00
TAG No. XXXXXXXX
Detector
DIA : 50 A
TYPE : MGG
EX : 300.0 mA
RANGE : SINGLE
ANA/DE : ANALOG XMTR
D1 : D1 NOT USED
DO : DO NOT USED
SW VER : 3.1
DAMP : 3.00
SPAN1 : 70.69 m3
GRAVITY : 1.0000
COEFF : 1.0000
LOFCUT : ON 0.6 %
F/S I : UP
DO : OPEN
P : HOLD
PULSE
CONF : ADD
RESET : 0000000000
WEIGHT : 110 cc/p
WIDTH : DUTY 50%
DROP : 0.5%
INPUT : 70.69 m3
OUTPUT : 100.02 %
STATUS CHECK= OK
Time when printed
Tag no.
Detector information
Diameter
Type
Detector constant
Range
Communication mode
Setting of contact input
Setting of contact output
Software version
Damping constant
Span
Specific gravity
Correction coefficient
Low flow cutoff
Burnout (4-20 mA output)
Burnout (Contact output)
Burnout (Pulse output)
Pulse information
Setting of built-in counter
Reset value
Pulse scale
Pulse width
Dropout value
Input value
Output value
Status
