Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 6-51
7
Press the key.
Result:
• The screen as shown on the right
appears and the set detector type is
confirmed.
8
or
Press the key or key to
display the screen (DOWN LOAD) as
shown on the right.
9
Press the key.
Result:
• The screen as shown on the right
appears and the changed setting is
written into the database of the
converter. The screen returns to step
3.
10
+
To exit this setting function, press the
+ keys.
11 Result:
• The screen exits the detector type
setting function and returns to step
1.
Step
Key Procedure SFC screen
