Azbil Corporation Operation using the data setting device

Model MTG11A/18A, MTG11B/18B, MTG14C 6-55

Continue to set the low alarm value.

Press the key or key to

display this screen. Actual low alarm

value appears.

7 Press numeric keys and enter the low

alarm value to be set.

Press the key.

The changed setting is saved to the

SFC.

Press the key or key to

show this screen.

Press the key.

The changed setting is written into

the database of the converter.

Setting is completed. Press the

key, and return to the screen as in

step 1.

Step

Key Procedure SFC screen

SFCM00006090D

SFCM00006091D

ENTER

( Yes )

NON-VOL

ENTER

( Yes )

NON-VOL

SFCM00006089D

SFCM00006092D

ENTER

( Yes )

NON-VOL

ENTER

( Yes )

NON-VOL

SFCM00006093D

CLR

( No )

CLR

( No )

SFCM00006009D
