Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 6-79
5
Press the key and select the
dropout to be set.
6
Press the key.
The changed setting is saved on the
SFC.
7
or
Next, set pulse width. press the
key or key to display
the screen as shown on the right.
8
Press the key.
Changed setting data is written into
the database of the converter.
9
Press the key and the screen
returns to the screen as in step 1.
Step Key Procedure SFC screen
MENU
I
ITEM
DE CONF.
MENU
I
ITEM
DE CONF.
SFCM00006154D
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006145D
H
NEXT
L
PREV
H
NEXT
L
PREV
SFCM00006152D
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006149D
CLR
( No )
CLR
( No )
SFCM00006009D
