Maintenance and troubleshooting Azbil Corporation
8-10 Model MTG11A/18A, MTG11B/18B, MTG14C
Table 8-1 Spare parts for integral type
No. Parts number Parts name
1 80382679-00100 Terminal assembly
2 HS309-230-16000 Screw
3 80383096-00100 Main board
4 80382689-00100 LCD board
5 83958309-00100 Spacers
6 HS311-530-06200 Screw
7 80382637-00100 Main LCD cable assembly
8 80381052-00100 Plug assembly (G1/2)
9 80020810-00600 Plug (1/2NPT)
10 80354400-00100 Plug assembly (CM20)
11 80352997-00100 Plastic gland
12 80356020-10100 Watertight gland assembly (brass Ni plated)
13 80382671-00100 Case (conduit connection G1/2, standard finish)
80382671-00200 Case (conduit connection 1/2NPT, standard finish)
80382671-00300 Case (conduit connection CM20, standard finish)
80382671-00400
Case (conduit connection G1/2, corrosion proof finish)
80382671-00500
Case (conduit connection 1/2NPT, corrosion proof finish)
80382671-00600
Case (conduit connection CM20, corrosion proof finish)
14 80382673-00100 Cover assemblies (display) (standard finish)
80382673-00200 Cover assemblies (display) (corrosion proof finish)
15 80277719-00100 Cover assemblies (terminal) (standard finish)
80277719-00300 Cover assemblies (terminal) (corrosion proof finish)
16 HS311-230-05000 Screw
17 80356995-00100 Screw
18 Refer to Table 8-4 Wafer type grounding ring assembly
18-1 Refer to Table 8-4 Screw
18-2 Refer to Table 8-4 PTFE gasket for grounding ring other than SUS
18 Refer to Table 8-5 Flange type grounding ring assembly
18-1 Refer to Table 8-5 Screw
18-2 Refer to Table 8-5 PTFE gasket for grounding ring other than SUS
