55
Lubrication areas
Open the protective part above
the knives system
There are 10 grease cups
(yellow) altogether in three areas
in the machine
 8 pieces on the lubrication
board
 1 piece on the left plate’s
arm
 1 piece on the lower
plate’s arm
