IS-28/28s
Baader Ísland ehf, Hafnarbraut 25, Kopavogur, IcelandTel: +354 520 6900 Fax: +354 520 6911
lager@baader.is / www.baader.is
9
PROTECTIVE PARTS
All flip-up protective parts of the machine are kept closed with a pump. No locks need
to be opened manually or with tools.
To open the machine it is enough to grasp the handle and pull it. The pump also
keeps the protective parts in the open position. It is good to hold the cover when
opening and closing.
Protective parts closed
Flip-up protective parts are specified
in fig. 5 and 6 in green. (IS-028s
shown)
