ADJUSTMENTS OF THE MACHINE
Gap between knives
- Loosen the bolt through the eccentric
(fig. 31, in yellow) with a 19 mm
spanner.
- Turn the eccentric (fig. 31, in red) with
a 26 mm spanner until the gap
between the knives is 2 mm
- Tighten the bolt again
- Move the knives to check if they are in
contact with an object
31
32
