Micro-Lens Models
A Lens
B Focusing Window
C Locking Clip
D Locking Screw
E Filter Cap (optional)
F Filter (optional)
NOTE: Filter Kits are available separately.
iVu Series Image Sensor
Rev. E www.bannerengineering.com - tel: 763-544-3164 43
