Banner Q4X User Manual

Beam Spot Size—100/110 mm Models
Table 11: Beam Spot Size—100/110 mm Models
Distance (mm) Size (Horizontal × Vertical)
Threaded Barrel Models Flush Mount Models
25 35 2.4 mm × 1.0 mm
50 60 2.2 mm × 0.9 mm
100 110 1.8 mm × 0.7 mm
Beam Spot Size—300/310 mm and 600/610 mm Models
Table 12: Beam Spot Size—300/310 mm and 600/610 mm Models
Distance (mm) Size (Horizontal ×
Vertical)
Threaded Barrel
Models
Flush Mount Models
25 35 2.6 mm × 1.0 mm
150 160 2.3 mm × 0.9 mm
300 310 2.0 mm × 0.8 mm
600 610 1.9 mm × 1.0 mm
Excess Gain using a 90% White Card—100/110/300/310 mm Models
Table 13: Excess Gain ( Excess Gain
1
)
Response Speed (ms) · at 25 mm (100/300 mm models)
· at 35 mm (110/310 mm models)
· at 100 mm (100/300 mm models)
· at 110 mm (110/310 mm models)
· at 300 mm (100/300 mm models)
· at 310 mm (110/310 mm models)
1.5 200 100 20
3 200 100 20
10 1000 (500) 500 (250) 100 (50)
25 2500 (1000) 1250 (500) 250 (100)
50 5000 (2500) 2500 (1250) 500 (250)
Excess Gain using a 90% White Card—600/610 mm Models
Table 14: Excess Gain ( Excess Gain
2
)
Response
Speed (ms)
· at 25 mm (600 mm models)
· at 35 mm (610 mm models)
· at 100 mm (600 mm models)
· at 110 mm (610 mm models)
· at 300 mm (600 mm models)
· at 310 mm (610 mm models)
· at 600 mm (600 mm models)
· at 610 mm (610 mm models)
2 280 110 25 6
5 280 110 25 6
15 1000 (360) 400 (150) 80 (30) 20 (7)
25 2000 (1000) 800 (400) 160 (80) 40 (20)
50 4000 (2000) 1600 (800) 320 (160) 80 (40)
Environmental Rating
IEC IP67 per IEC60529
IEC IP68 per IEC60529
IEC IP69K per DIN40050-9
Vibration
MIL-STD-202G, Method 201A (10 Hz to 60 Hz, 0.06 inch (1.52 mm) double
amplitude, 2 hours each along X, Y and Z axes), with sensor operating
Shock
MIL-STD-202G, Method 213B, Condition I (100G 6x along X, Y and Z axes, 18
total shocks), with sensor operating
Operating Conditions
−10 °C to +50 °C (+14 °F to +122 °F)
35% to 95% relative humidity
Storage Temperature
–25 °C to +75 °C (−13 °F to +167 °F)
1
• excess gain available in 10 ms, 25 ms, and 50 ms response speeds only
• excess gain provides increased noise immunity
2
• excess gain available in 15 ms response speed only
•
excess gain provides increased noise immunity
Q4X Stainless Steel Laser Sensor with Dual Discrete Outputs and IO-Link
www.bannerengineering.com - Tel: 763.544.3164 31
