Specifications
Sensing Beam
Visible red Class 1 laser, 655 nm
Supply Voltage (Vcc)
10 to 30 V dc (Class 2 supply) (10% max ripple within limits)
Power and Current Consumption, exclusive of load
< 700 mW
Sensing Range—Threaded Barrel Models
600 mm models: 25 mm to 600 mm (0.98 in to 23.62 in)
300 mm models: 25 mm to 300 mm (0.98 in to 11.81 in)
100 mm models: 25 mm to 100 mm (0.98 in 3.94 in)
Sensing Range—Flush Mount Models
610 mm models: 35 mm to 610 mm (1.38 in to 24.02 in)
310 mm models: 35 mm to 310 mm (1.38 in to 12.20 in)
110 mm models: 35 mm to 110 mm (1.38 in to 4.33 in)
Output Configuration
First output = IO-Link, Push/pull
Secondary output = PNP only output or input, or pulse frequency modulated
output
Output Rating
100 mA max capability each output
100 mA max total load current for sensor
Saturation: < 2 V
Off-state leakage current: < 50 µA PNP at 30 V (N.A. push/pull)
Discrete Output Distance Repeatability
Table 8: 600/610 mm Models
Distance (mm) Repeatability
Threaded Barrel Models Flush Mount Models
25 to 100 mm 35 to 110 mm ± 0.5 mm
100 to 600 mm 110 to 610 mm ± 0.5%
Table 9: 300/310 mm Models
Distance (mm) Repeatability
Threaded Barrel Models Flush Mount Models
25 to 50 mm 35 to 60 mm ± 0.5 mm
50 to 300 mm 60 to 310 mm ± 1% of range
Table 10: 100/110 mm Models
Distance (mm) Repeatability
Threaded Barrel Models Flush Mount Models
25 to 100 mm 35 to 110 mm +/-0.2 mm
Remote Input
Allowable Input Voltage Range: 0 to Vcc
Active High (internal weak pulldown): High state > (VCC - 2 V) @ 1.5 mA max.
Supply/Output Protection Circuitry
Protected against reverse polarity and transient overvoltages
Response Speed
User selectable, 100, 110, 300, and 310 mm models:
•
—1.5 milliseconds
• —3 milliseconds
• —10 milliseconds
• —25 milliseconds
• —50 milliseconds
User selectable, 600 and 610 mm models:
•
—2 milliseconds
• —5 milliseconds
• —15 milliseconds
• —25 milliseconds
• —50 milliseconds
Delay at Power Up
100, 110, 300, 310 mm models: < 750 ms
600, 610 mm models: < 1.5 s
Maximum Torque
Side mounting: 1 N·m (9 in·lbs)
Nose mounting: 20 N·m (177 in·lbs)
Ambient Light Immunity
> 5,000 lux at 300 mm
> 2,000 lux at 600 mm
Connector
Integral 4-pin M12/Euro-style male quick disconnect (QD)
Construction
Housing: 316 L stainless steel
Lens cover: PMMA acrylic
Lightpipe and display window: polysulfone
Temperature Effect
0.05 mm/°C at < 125 mm (threaded barrel models)/< 135 mm (flush
mount models)
0.35 mm/°C at 300 mm (threaded barrel models)/310 mm (flush mount
models)
1.0 mm/°C at 600 mm (threaded barrel models)/ 610 mm (flush mount
models)
Chemical Compatibility
Compatible with commonly used acidic or caustic cleaning and
disinfecting chemicals used in equipment cleaning and sanitation.
ECOLAB
®
certified.
Compatible with typical cutting fluids and lubricating fluids used in
machining centers
IO-Link Interface
Supports Smart Sensor Profile: Yes
Baud Rate: 38400 bps
Process Data Widths: 16 bits
IODD files: Provides all programming options of the display, plus
additional functionality.
Application Note
For optimum performance, allow 10 minutes for the sensor to warm up
Q4X Stainless Steel Laser Sensor with Dual Discrete Outputs and IO-Link
30 www.bannerengineering.com - Tel: 763.544.3164
