Table of Content
Disassemble Left Lamp Driver 2-45
Disassemble Fan Module (120X120X25 mm) 2-48
Disassemble Fan Module (105X32 mm) 2-49
Disassemble Blower Module (60X25 mm) 2-51
Disassemble Right Air Vent 2-52
Disassemble Left Air Vent 2-52
Disassemble Bottom Cover Module 2-53
Rod Adjustment 2-56
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Equipment Needed 3-3
Main Procedure 3-4
Power Troubleshooting 3-5
Image Performance Troubleshooting 3-7
Remote Control Troubleshooting 3-11
Network Troubleshooting 3-12
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode and Hidden Menu 4-1
OSD Reset 4-2
Reset Lamp Hour 4-2
Test Condition 4-3
