Barco CLM W6 Service Manual

3-1
CLM W6_CLM HD6 Jan 31, 2012
Chapter 3 Troubleshooting
3-1 LED Lighting Message
Power
Lamp
1 Error
Lamp
2 Error
Temp Error Remark
LED color Blue Green Red Red Red Red
Standby State
(Input power cord &
switch on)
ON OFF OFF OFF OFF OFF
Power off (Cooling) /
Power on (Warm up)
OFF
Flash-
ing
OFF OFF OFF OFF
“Green Power LED” ashing
refers to “Cooling / warm up”
Normal operating OFF ON OFF OFF OFF OFF Normal operating.
Thermal sensor error OFF ON OFF OFF ON
Flash-
ing
“Red Error LED” ashing refers
to “Overheating”.
Fan lock error
(OSD shows “Fan
Fail”)
OFF ON OFF OFF OFF
Flash-
ing
“Red Error LED” ashing refer
to “Fan failure”.
Lamp striking fail
(Both)
OFF
Flash-
ing
ON OFF OFF OFF
“Green Power LED” ashing
refers to “Cooling / warm up”.
Lamp striking fail
(Lamp 1)
OFF
Flash-
ing
ON OFF OFF OFF
“Green Power LED” ashing
refers to “Cooling / warm up”.
Lamp striking fail
(Lamp 2)
OFF
Flash-
ing
OFF ON OFF OFF
“Green Power LED” ashing
refers to “Cooling / warm up”.
