Barco CLM W6 Service Manual

3-2
CLM W6_CLM HD6 Jan 31, 2012
Chapter 3 Troubleshooting
Power
Lamp
1 Error
Lamp
2 Error
Temp Error Remark
LED color Blue Green Red Red Red Red
Lamp1 error (Lamp,
ballast)
OFF ON
Flash-
ing
OFF OFF
Flash-
ing
1. Lamp fail during normal
operation
2. “Lamp 1 LED” & “Error LED”
ashing refer to lamp 1
Lamp2 error (Lamp,
ballast)
OFF ON OFF
Flash-
ing
OFF
Flash-
ing
1. Lamp fail during normal
operation
2. “Lamp 2 LED” & “Error LED”
ashing refer to lamp 2
System error 1.
“Lamp LED” ashing
refer to lamp failure.
(color wheel fail,…
ETC)
OFF ON
Flash-
ing
Flash-
ing
OFF
Flash-
ing
1. Lamp fail during normal
operation
2. “Lamp LED” & “Error LED”
ashing refer to lamp
Download mode OFF OFF ON ON ON ON
All components (Scalar, PIC...)
download will apply the same
behavior.
