Chapter 2 Disassembly Process
2-49
CLM W6_CLM HD6 Jan 31, 2012
3. Separate fan holder
, rubber and fan.
2-23
Disassemble Fan Module
(105X32 mm)
1. Unscrew 2 screws (red circle) to
remove fan module (105X32 mm).
59
61
