Barco CLM W6 - Image and Input Settings

Chapter 2 Disassembly Process
2-18
CLM W6_CLM HD6 Jan 31, 2012
7. Disassemble Keypad board module.
2-12 Disassemble Connector
Board
1. Unplug 21 connectors (yellow square).
Remove 1 LED cable.
LED Cable
