Chapter 2 Disassembly Process
2-19
CLM W6_CLM HD6 Jan 31, 2012
2. Unscrew 2 screws (yellow circle) to
remove keypad cable.
3. Unscrew 2 screws (red circle) to
remove connector board.
Note: Make sure to plug each connector
in the right position on the connector board
during assembly procedure.
Please refer to the table below for the
details of the connectors on connector
board.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
16
19
20
21
To Next Page
