3-3
CLM W6_CLM HD6 Jan 31, 2012
Chapter 3 T
roubleshooting
3-2 Equipment Needed
1. Projector
2. PC (Personal computer)
3. DVD player
4. Screw drivers
5. VGA
cable, power cord, component cable, audio cable,HDMI cable
6. V
oltage test meter
