4-1
CLM W6_CLM HD6 Jan 31, 2012
Chapter 4 Function Test & Alignment Procedure
4. Function Test & Alignment Procedure
4-1 Test Equipment Needed
- IBM PC with WUXGA/WXGA resolution
- DVD player with Multi-system, equipped "Component", "S-Video", "Composite" and "HDMI".
- HDTV Source (480P, 720P, 1080P)
- Minolta CL-100
- Quantum Data 802B or CHROMA2327 (Color Video Signal & Pattern Generator)
4-2 Service Mode and Hidden Menu
- CLM W6/CLM HD6 contain 2 kinds of mode
1. Service Mode
(1) Turn on the projector
(2) Press "Menu" button on Remote Controller or Keypad, choose "Service" to get into Service
Mode.
2. Hidden menu
Do the following actions sequentially to get into Hidden menu
(1) Turn on the projector without inputting any signal.
(2) Press the following buttons
- With hidden code key combination to get into Hidden menu.
(Arrow "up" --> "down" --> "left' --> "right" --> "up" --> "down")
To Next Page
