Chapter 2 Disassembly Process
2-47
CLM W6_CLM HD6 Jan 31, 2012
3. Unplug 2 connectors (yellow square) to
disassemble 3 wires.
Separate two wires (red circle)
4. Loosen 4 tenons (yellow circle) to
disassemble Left Lamp Driver
.
