Chapter 3 Troubleshooting
3-5
CLM W6_CLM HD6 Jan 31, 2012
3-4 Power Troubleshooting
J1
Pin Voltage
4 +5V
J1
Pin Voltage
1 +12V
2 +12V
3 +12V
14 +12V
15 +12V
16 +12V
J1 of main board
J17 of main board
