4-7
CLM W6_CLM HD6 Jan 31, 2012
Chapter 4 Function Test & Alignment Procedure
Full white
- The PC mode functionally should be workable
include support format with frequency and auto
detected functional will be workable.
2. Bright Pixel
Procedure - Test equipment: video generator
- Test signal: 1920 x 1080 @60Hz
- Test Pattern: Gray 10
Inspection item - Bright pixel check
Criteria - Bright pixel is unacceptable in the active zone
for CLM HD6, 1 pixel is allowed for CLM W6.
1 pixel is allowed on the frame for all.pixel is allowed on the frame for all.
- Adjacent pixels are unacceptable.
- Ref. Defect specication table
3. Dark Pixel
Procedure - Test equipment: video generator
- Test signal: 1920 x 1080 @60Hz
- Test Pattern: Full white
Inspection item - Dark pixels check
Criteria - The dark pixel should be no more than 6 under
full white pattern.
- Adjacent pixels are unacceptable.
- Ref. Defect specication table
4. Bright Blemish
Procedure - Test equipment: video generator
- Test signal: 1920 x 1080 @60Hz
- Test Pattern: Gray 15
Inspection item - Bright blemish check
Criteria - The bright blemish should be no more than 10
under gray 15 pattern.
- Ref. Defect specication table
Gray 15
Gray 10
