106 PDS • User’s Guide
^K==péÉÅáÑáÅ~íáçåë
Input Specifications
fåéìí=péÉÅáÑáÅ~íáçåë=
The table below lists PDS input specifications.
lìíéìí=péÉÅáÑáÅ~íáçåë
The table below lists PDS output specifications:
Table A-1. PDS Input Specifications
Parameter Detail Specification
Inputs 1 - 4 Connector HD-15 VGA
Format RGBHV / RGBS / RGsB computer video, YPbPr video
(SD or HD), S-video, or composite video
Sampling 10-bits/color at 150 MHz maximum
Supports 1:1 sampling up to 1920x1080p @60Hz
Sources with native pixel rates > 150 MHz will be filtered
and undersampled at 150 Mhz, including:
• 1600x1200@60 (162 MHz)
• 1920x1080p@60 (173.0 MHz)
• 1920x1200@60 (193.25 MHz)
• 2048x1080p@60 (183.75 MHz)
Inputs 5 - 8
Connector DVI-I, per DDWG 1.0
Format (Digital) 8-bit DVI, RGBHV data via analog pins
Format (Analog) RGBHV / RGBS / RGsB computer video, YPbPr video
(SD or HD), S-video, or composite video
HDCP hardware support HDCP version 1.0 compliant
Input 9
Connector BNC
Format SD-SDI per SMPTE 259M-C (NTSC/PAL resolution)
HD-SDI per SMPTE 292M (HDTV)
3G-SDI per SMPTE 425
Table A-2. PDS Output Specifications
Parameter Detail Specification
Outputs DVI output 1 x DVI connector
RGB output 1 x HD-15 VGA connector
HDCP Encryption On DVI connector only
