Barco PDS User Manual

138 PDS • User’s Guide
_K==oÉãçíÉ=`çåíêçä
Remote Commands
lìíéìí=`çãã~åÇë
_i^`h=
• Description: Set the mixer to output black.
• Command Format: BLACK -m (mode)
• Parameters: -m (mode): 0 - off, 1 - on
• Query Format: BLACK -?
• Query Response: BLACK -m (mode) --min 0 --max 1
l^s^fi
• Description: Query-only command used to identify whether the preview output
mezzanine is installed
• Query Format: OAVAIL -o (output) -?
• Parameters:
-o (output): 1 - DVI, 3 - Preview DVI
-m (mode): 0 - output not available, 1 - output available
• Query Response: OAVAIL -o (output) -m (mode)
l`p^s=
• Description: Save Output Configuration
• Command Format: OCSAV
• Parameters: -o output: 1 - DVI, 3 - Preview DVI (PDS-902 only)
• Query Format: N/A
• Query Response: N/A
ldj=
• Description: Set Output Gamma
• Command Format: OGM -o (output) -g (gamma)
• Parameters:
-o output: 1 - DVI
-g gamma: 1.0 to 3.0; +0.1 increment (Default: 1.0)
• Query Format: OGM -o (output) -?
• Query Response: OGM -o (output) -g (gamma) --min 1 -- max 3
lo_j=
• Description: Output Raster Box Mode
• Command Format: ORBM -o (output) -m (mode)

Barco PDS Specifications

General

Layers	2
HDCP Support	Yes
Output Resolutions	480i, 576i, 480p, 576p, 720p, 1080i, 1080p, 4K
Control	Ethernet, RS-232, Web UI
Transition Effects	Wipes, fades, dissolves
Ports	Ethernet, RS-232
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Dimensions	440 x 44 x 220 mm
