Barco PDS - Output Menu

50 PDS • User’s Guide
4. Operation
Setup Menu
lìíéìí=jÉåì
From the Setup Menu, select Output to display the Output Menu.
Figure 4-24. Output Menu (sample)
Following are descriptions of each Output Menu function:
• Main
• Preview Menu (PDS 902 Only)
j~áå
Following are descriptions of each Output Menu function:
• Output Format
• Test Pattern
• Output Adjust
• Sync Settings
• Gamma
• Save Config
lìíéìí=cçêã~í
From the Output Menu, select the top Output Format line to view or change the current
output format. This line indicates the format in the following form:
Hact x Vact @ Vr Hz
The output format for the PDS can be set to any of the progressive outputs.
qÉëí=m~ííÉêå
From the Output Menu, select Test Pattern to display the Test Patterns Menu:
Figure 4-25. Test Patterns Menu (sample)
The following functions are available on the menu:
• Mode — This function enables or disables the test pattern generator.
OUTPUT
> Main >>
Preview >>
Note
The output format is not updated until SEL is pressed.
TEST PATTERN
> Mode ON
Type Burst
Raster Box OFF
