PDS • User’s Guide 111
^K==péÉÅáÑáÅ~íáçåë
Pinouts
bíÜÉêåÉí=`çååÉÅíçê
The figure below illustrates the Ethernet connector:
Figure A-3. Ethernet connector
The table below lists Ethernet connector pinouts.
Table A-8. Ethernet Connector Pinouts
Pin Signal Wire Color
1 TX Data + White / Orange
2 TX Data - Orange
3 RX Data + White / Green
4Blue
5 White / Blue
6 RX Data - Green
7 White / Brown
8Brown
18

Barco PDS Specifications

General

Layers	2
HDCP Support	Yes
Output Resolutions	480i, 576i, 480p, 576p, 720p, 1080i, 1080p, 4K
Control	Ethernet, RS-232, Web UI
Transition Effects	Wipes, fades, dissolves
Ports	Ethernet, RS-232
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Dimensions	440 x 44 x 220 mm
