PDS • User’s Guide 39
4. Operation
Setup Menu
• When the following formats are detected as either SD-SDI, HD-SDI, or 3G-SDI,
only [SMPTE] is shown.
^ìíç=^ÅèìáêÉ
The Auto Acquire field is only adjustable between ON and OFF when Auto Acquire is set
to INPUT in the User Preference Menu (refer to the “User Preference Menu
” section on
page 58).
When Auto Acquire is ON, and an input has a saved configuration file, the system
attempts to use the saved file. If the input timing matches the timing in the saved
configuration file, the saved file is used.
The system always performs a full sync (timing) acquisition on the selected input signal
under the following conditions:
• When an input without a saved configuration file is selected
• When the input type is changed
• When the input signal’s sync rate is changed
• When an input with a saved configuration file is selected, but the input timing is
different from the saved configuration
When Auto Acquire is ON, and the input source is non-digital, the system uses the
following library search order:
• Saved configuration files defined in the File Association Menu for each input
channel
• The user’s library of saved files
• A best guess
When Auto Acquire is ON, and the input source is digital, the system uses the following
search order:
• Saved configuration files defined in the File Association Menu for each input
channel
• The user’s library of saved files
~ NTSC (480i)
~ PAL (576i)
~ 1280x720p @50
~ 1280x720p @59.94
~ 1280x720p @60
~ 1920x1080p @23.98
~ 1920x1080p @24
~ 1920x1080p @25
~ 1920x1080p @29.97
~ 2048x1080p @23.98
~ 2048x1080p @25
~ 2048x1080p @30
~ 2048x1080p @48
~ 2048x1080p @59.94
~ 1920x1080p @30
~ 1920x1080sF@23.98
~ 1920x1080sF@24
~ 1920x1080i @50
~ 1920x1080i @59.94
~ 1920x1080i @60
~ 1920x1080p @50
~ 1920x1080p @59.94
~ 1920x1080p @60
~ 2048x1080p @24
~ 2048x1080p @29.97
~ 2048x1080p @47.95
~ 2048x1080p @50
~ 2048x1080p @60
