pjmqb=`çäçê=_~ä~åÅÉ=jÉåì
If the current input’s colorspace is set to SMPTE, the Color Balance Menu appears:
Figure 4-16. Color Balance Menu (SMPTE sample)
Please note:
• Saturation is measured in percentage.
~ Adjustment range (Composite, S-Video, YP
b
P
r
, SDI): 0% to 150%
(100% nominal)
• Hue is measured in degrees, and is [N/A] for YP
b
P
r
and SDI inputs.
~ Adjustment range: -90 to +90
• Select Reset All to set all values back to their default settings.
mêçÅÉëëáåÖ
From the Input Menu, select Processing to display the Processing Menu:
Figure 4-17. Processing Menu (sample)
The following functions are available:
• Sync Selection — This function applies only to Analog RGB inputs. The
PDS automatically selects the syncs for digital sources, composite, S-video, and
YP
b
P
r
inputs. For these inputs, the value field indicates [N/A].
The sync choices are Auto, H/V (horizontal/vertical sync), CSync (composite
sync) and SOG (sync on green).
~ In Auto mode, the system finds sync in any of the three possible
sources.
• If one of the sources is chosen, the system uses only that input
as a sync source.
• If the system does not find sync at that source, it acts as if it is in
Auto mode.
~ The default selection for Analog RGB inputs is Auto.
• Pulldown Compensation — This function only applies to standard video
(component, s-video, composite and SD/HD SDI) inputs. The mode, which
detects the 3:2 film pulldown sequence, should be turned ON to properly process
video derived from film source material.
COLOR BALANCE
> Saturation 100
Hue 0
Reset All
PROCESSING
> Sync Sel Auto
Pulldown Comp OFF
Sync Slice 128
To Next Page
