52 PDS • User’s Guide
4. Operation
Setup Menu
position in lines. Positioning is limited to the overall maximum V Size “space”, and
the image cannot be moved off screen.
• Reset All— This function resets H and V Size to the currently selected output
format resolution, and H and V Position to [0].
póåÅ=pÉííáåÖë
From the Output Menu, select Sync Setup to display the Output Sync Select Menu:
Figure 4-27. Output Sync Select Menu (sample)
The Output Sync Select Menu enables you to independently adjust the output sync
polarity of the Analog and DVI outputs. The following functions are available:
• HD-15 Sync — This field sets the analog output sync polarity.
~ Values: CSync, -H-V, -H+V, +H-V, +H+V
~ Default: -H-V
• DVI Sync — This field sets the DVI output sync polarity.
~ Values: -H-V, -H+V, +H-V, +H+V
~ Default: +H+V
d~ãã~
From the Output Menu, select Gamma to specify the output Gamma.
• Adjustment range: 1.0 to 3.0, in steps of 0.1
• Default: 1.0
p~îÉ=`çåÑáÖ
From the Output Menu, select Save Config to save the current output configuration. A
message is briefly shown, after which the system returns to the Output Menu.
Figure 4-28. Saving Output Configuration Message
Please note the following important points regarding the output configuration file:
• When you perform the Save Config function, all configuration parameters from
the Output Menu are saved in non-volatile memory. If you do not perform the
function, output data will not be restored upon the next system power up.
OUTPUT SYNC SELECT
> HD-15 Sync -H-V
DVI Sync +H+V
Saving Output Config
