140 PDS • User’s Guide
_K==oÉãçíÉ=`çåíêçä
Remote Commands
• Query Response: OSRC -s (source)
• List Format: OSRC --list
• List Response:
0:"Preview"
1:"Program"
lpvk`=
• Description: Output Sync Type Adjust.
• Command Format: OSYNC -o (output) -s (sync)
• Parameters:
-o output: 1 - DVI, 2- Analog, 3 - Preview DVI, 4 - Preview Analog
(3 and 4 are for PDS-902 only)
-s (sync): 1 = +H+V, 2 = +H-V, 3 = -H+V, 4 = -H-V, 5=CSync for analog
only (Defaults: DVI: +H+V, analog: based on Output Format selected)
• Query Format: OSYNC -o (output) -?
• Query Response: OSYNC -o (output) -s(sync) --min 1 --max 4 (max returned for
analog is 5)
• List Format: OSYNC -o (output) --list
• List Response:
1:"+H+V"
2:"+H-V"
3:"-H+V"
4:"-H-V"
5:”CSync” (returned for analog only)
lqmj=
• Description: Output Test Pattern Mode
• Command Format: OTPM -o (output) - m (mode)
• Parameters:
-o output: 1 - DVI, 3 - Preview DVI (PDS-902 only)
-m (mode): 0 - off, 1 - on
• Query Format: OTPM -o (output) -?
• Query Response: OTPM -o (output) - m (mode) --min 0 -- max 1
lqmq=
• Description: Output Test Pattern Type
• Command Format: OTPT -o (output) - t (type)
• Parameters: -o output: 1 - DVI, 3 - Preview DVI (PDS-902 only)
• -t (type): 1 - H Ramp
2 - V Ramp

Barco PDS Specifications

General

Layers	2
HDCP Support	Yes
Output Resolutions	480i, 576i, 480p, 576p, 720p, 1080i, 1080p, 4K
Control	Ethernet, RS-232, Web UI
Transition Effects	Wipes, fades, dissolves
Ports	Ethernet, RS-232
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Dimensions	440 x 44 x 220 mm
